Structure parameters | value | |
Housing material | 304 grade stainless steel | |
Thickness | 1.5mm+1.2mm | |
Surface treatment | Brushed finish | |
Technical parameters | 550-900mm | |
Size | 330*420*980mm | |
Lane width | 600mm | |
Passing speed | 0.2sec | |
Passing speed | 35--50 people/min | |
Weight | 35KG | |
Turning angle | 120 degree | |
MCBF | 5.000.000 times | |
Application | Indoor or outdoor | |
Rotating directional | Single way or Bi-directional adjustable | |
Noise | <55db | |
Operating temperature | -15 to 70℃ | |
Relative humidity | 5% to 95% | |
Package | Carton box inside. Wooden case outside | |
Electronic parameters | Dry contact | |
Power supply | 110-220V/AC, 50/60HZ | |
Rated power | 100W | |
Input signal | Dry contact | |
Driving motor | Solenoid |
